We design CP-CPT-CPJ marine jet pump series for different needs, you can choose according to specific application, or send us your customized needs.
The CP series marine jet pumps are fundamental in ship applications. They are mainly deployed in ship drainage systems and find use in industries like environmental protection, chemical engineering, water conservancy, and building materials. Capable of pumping various fluids, mixing liquids, river dredging, and powder conveyance.
In the CPT series, "T" denotes "perpendicular type". The suction flange axis is perpendicular to the pump body axis. Characterized by a simple structure with no moving parts, ensuring a long service life and excellent self - priming performance for continuous and stable operation.
For the CPJ series, "J" represents a specific inlet feature. The suction flange axis is coaxial with the pump body axis. These pumps offer high - efficiency operation and easy installation, suitable for diverse liquid - handling scenarios
| Type |
Capacity m3/h |
Delivery m |
suction-head m |
working-pressure MPa |
water-consumption m3/h |
weight kg |
| CP5-0.7 | 5 | 8 | 4 | 0.7 | 3.6 | 9 |
| CP5-0.3 | 5 | 5 | 4 | 0.3 | 6 | 17 |
| CP10-0.7 | 10 | 8 | 4 | 0.7 | 7 | 12.5 |
| CP10-0.3 | 10 | 5 | 4 | 0.3 | 12 | 23 |
| CP15-0.5 | 15 | 11 | 7 | 0.5 | 24 | 27 |
| CP15-0.3 | 15 | 5 | 4 | 0.3 | 19 | 27 |
| CP15-0.7 | 15 | 15 | 4 | 0.7 | 27 | 27 |
| CP20-0.7 | 20 | 8 | 4 | 0.7 | 14 | 20 |
| CP20-0.3 | 20 | 5 | 4 | 0.3 | 24 | 30 |
| CP30-0.7 | 30 | 8 | 4 | 0.7 | 21 | 28 |
| CP30-0.3 | 30 | 5 | 4 | 0.3 | 36 | 43 |
| CP40-0.3 | 40 | 5 | 4 | 0.3 | 47 | 43 |
| CP50-0.7 | 50 | 8 | 4 | 0.7 | 35 | 45 |
| CP50-0.3 | 50 | 6 | 3 | 0.3 | 55 | 50 |
| CP100-0.7 | 100 | 9 | 2 | 0.7 | 60 | 68.5 |
| CP100-0.3 | 100 | 6 | 3 | 0.3 | 110 | 88 |
| CP200-0.7 | 200 | 9 | 2 | 0.7 | 120 | 112 |
| Type |
Capacity m3/h |
Delivery m |
suction-head m |
working-pressure MPa |
water-consumption m3/h |
weight kg |
| CP5-0.7T | 5 | 8 | 4 | 0.7 | 3.6 | 9 |
| CP5-0.3T | 5 | 5 | 4 | 0.3 | 6 | 17 |
| CP10-1.0T | 10 | 20 | 5 | 1.0 | 16.7 | 12 |
| CP10-0.7T | 10 | 8 | 4 | 0.7 | 7 | 12 |
| CP10-0.3T | 10 | 5 | 4 | 0.3 | 12 | 23.5 |
| CP15-0.5T | 15 | 11 | 7 | 0.5 | 24 | 25.5 |
| CP15-0.3T | 15 | 5 | 4 | 0.3 | 19 | 25.5 |
| CP15-0.7T | 15 | 15 | 4 | 0.7 | 27 | 25.5 |
| CP20-0.7T | 20 | 8 | 4 | 0.7 | 14 | 22.5 |
| CP20-0.3T | 20 | 5 | 4 | 0.3 | 24 | 29.5 |
| CP30-0.7T | 30 | 8 | 4 | 0.7 | 21 | 27 |
| CP30-0.3T | 30 | 5 | 4 | 0.3 | 36 | 50 |
| CP40-1.0T | 40 | 8 | 4 | 1.0 | 24 | |
| CP40-0.3T | 40 | 5 | 4 | 0.3 | 47 | 50 |
| CP50-1.0T | 50 | 20 | 5 | 1.0 | 64 | 52 |
| CP50-0.7T | 50 | 8 | 4 | 0.7 | 35 | 43.5 |
| CP50-0.3T | 50 | 6 | 3 | 0.3 | 55 | 54.5 |
| CP60-0.7T | 60 | 6 | 6 | 0.7 | 50 | 55.5 |
| CP80-0.7T | 80 | 10 | 5 | 0.7 | 90 | 54 |
| CP100-0.7T | 100 | 9 | 2 | 0.7 | 60 | 68.5 |
| CP100-0.3T | 100 | 6 | 3 | 0.3 | 110 | 72.5 |
| CP100-0.2T | 100 | 7 | 3 | 0.2 | 305 | 170 |
| CP120-1.0T | 120 | 9 | 2 | 0.7 | 120 | 106 |
| CP150-0.7T | 150 | 9 | 2 | 0.7 | 100 | 75 |
| CP100-0.75T | 80 | 15 | 5 | 0.75 | 123 | 90 |
| CP200-0.7T | 200 | 9 | 2 | 0.7 | 120 | 106 |
| CP30/20-0.7T | 30 | 15 | 5 | 0.7 | 40 | 32 |
| Type |
Capacity m3/h |
Delivery m |
suction-head m |
working-pressure MPa |
water-consumption m3/h |
weight kg |
| CPJ40-50-65 | 10 | 10 | 5 | 0.7 | 10 | 18.5 |
| CPJ50-80-80 | 20 | 15 | 5 | 0.7 | 32 | 26 |
| CPJ80-100-100 | 50 | 12 | 5 | 0.7 | 60 | 40 |
| CPJ80-125-125 | 50 | 15 | 7 | 0.7 | 70 | 60 |
| CPJ100-125-125 | 60 | 12 | 5 | 0.7 | 90 | 60 |
| CPJ100-150-150 | 0-120 | 5-30 | 3-9 | 0.4-1.4 | 90-150 | 75 |
| CPJ125-150-200 | 130 | 20 | 5 | 0.9 | 200 | 130 |
| CPJ150-200-200 | 0-320 | 5-30 | 3-9 | 0.4-1.4 | 200-370 | 165 |
| CPJ150-200-250 | 0-420 | 5-30 | 3-9 | 0.4-1.4 | 250-500 | 180 |
| CPJ200-200-250 | 0-250 | 5-30 | 1-7 | 0.1-0.6 | 300-700 | 190 |
| CPJ250-250-300 | 0-400 | 5-30 | 1-7 | 0.1-0.6 | 500-1400 | 285 |
| CPJ300-300-350 | 0-600 | 5-30 | 1-7 | 0.1-0.6 | 900-2000 | 370 |
