Brand: Advance Model: 2F700
| Product Description | The 2F700 marine oil water gearbox features single input and dual output, with clutch functionality. Its transmission method is an external meshing cylindrical helical gear five-shaft five-tooth two-stage drive. It consists of three main transmission components: input, transmission, and output. Hydraulic control elements enable manual or electro-hydraulic and pneumatic control. It is used to drive the oil pump. | |||
| Main technical parameters | Input speed | 900r/min | ||
| gear ratio | 1 | Transfer Capacity | 0. 5kw/r/min | |
| Manipulate Way | Pull and push flexible shaft, electric control | |||
| Center distance | 2×500mm | |||
| Length x width x height | 1540×1024×1550mm | |||
| net weight | 1190kg | |||
| Connect the flywheel | Input side equipped with highly flexible coupling, output side with elastic pin coupling | |||
| Bell housing | without | |||
| Application Area | Mainly used for the output of ship auxiliary gear box oil pump. | |||
Brand: Advance Model: 2LZF650
| Product Description | The 2LZF650 type marine oil water gearbox features single input and dual output, with clutch functionality. Its transmission form is an external meshing cylindrical helical gear six-shaft nine-tooth two-stage speed reduction. The two oil pumps consist of three main transmission components: input, transmission, and output. The motor output comprises three primary transmission components: input, fast/slow shaft, and motor output. Hydraulic control components can achieve manual control or electro-hydraulic control, as well as pneumatic control. | |||
| Main technical parameters | Input speed | 650~1000r/min | ||
| speed increasing ratio | 2.005 (fast gear motor) | Transfer Capacity | 0.138kw/r/min | |
| 1.71 (slow motor) | 0.131 kw/r/min | |||
| 2.01 (drive oil pump) | 0.122 kw/r/min | |||
| Manipulate Way | Pull and push flexible shaft, electric control, pneumatic control | |||
| Center distance | 403mm (oil pump output) 310mm (motor output) | |||
| Length x width x height | 1000×730×935mm | |||
| net weight | 650kg | |||
| Bell housing | without | |||
| Application Area | Primarily used for marine auxiliary gearboxes to drive gear pumps, vane pumps, and motor outputs. | |||
Brand: Advance Model: LJH1400
| Product Description | The LJH1400 type marine oil water gearbox has functions of braking, clutching, and torque transmission. Its transmission form is external meshing cylindrical helical gears with two shafts and two teeth for step-by-step reduction. The gearbox consists of two main transmission components: input and output. Hydraulic control components can achieve manual control or electro-hydraulic and pneumatic control. | |||
| Main technical parameters | Input speed | 1000r/min | ||
| reduction gear ratio | i=3.39 | Transfer Capacity | 1.12 kw/r.min-1 | |
| Manipulate Way | Pull and push flexible shaft, electric control | |||
| Center distance | 490mm | |||
| Length x width x height | 1568×1389×1383mm | |||
| net weight | 3560kg | |||
| Bell housing | without | |||
| Application Area | Mainly used to drive the oil pump output of auxiliary gear box for ship. | |||
Brand: Advance Model: LZ3000
| Product Description | The LZ3000 type marine gearbox features speed reduction and smooth clutch function. Its transmission form is an external meshing cylindrical helical gear with two shafts and two teeth for primary speed reduction. It consists of two main transmission components: input and output. Hydraulic control components can achieve manual control or electro-hydraulic and pneumatic control. It is used to drive high-power oil pumps. | |||
| Main technical parameters | Input speed | 370-600r/min | ||
| speed increasing ratio | 2.97 | Transfer Capacity | 2.9kw/r/min | |
| Manipulate Way | Pull and push flexible shaft, electric control | |||
| Center distance | 490mm | |||
| Length x width x height | 1395×1230×1550mm | |||
| net weight | 1550kg | |||
| Connect the flywheel | SAE21 18 | |||
| Bell housing | without | |||
| Application Area | Mainly used for the output of ship auxiliary gear box oil pump. | |||
Brand: Advance Model: LZF1000
| Product Description | The LZF1000 transfer case features speed increase and clutch function. This gearbox has one input and one output, with two gear ratios for fast and slow speeds. Its transmission form is an external meshing cylindrical helical gear four-shaft six-tooth two-stage speed increase. It adopts an electronically controlled shift-clutch structure, offering advantages such as quick shifting, smooth engagement, and stability. | |||
| Main technical parameters | Input speed | 1000 r/min | ||
| speed increasing ratio | 1.79 fast | Transfer Capacity | 0.239kw/r/min | |
| 1.969 slow | 0.262kw/r/min | |||
| Manipulate Way | drive-by-wire | |||
| Center distance | 244.78mm | |||
| Length x width x height | 886×490×963mm | |||
| Bell housing | not have | |||
| Application Area | Mainly used to drive the oil pump and motor output of auxiliary gearboxes for fishing boats. | |||
