Brand: Advance Model: 4LZF1100A
| Product Description | The 4LZF1100A type marine generator gearbox features a gear pump, vane pump, motor, clutch, and torque transmission. Its drive mechanism is an external meshing cylindrical helical gear with seven axes and ten teeth for two-stage reduction. The gearbox consists of seven main transmission components: input, transmission, and output. Hydraulic control elements enable manual or electro-hydraulic and pneumatic control. | |||
| Main technical parameters | Input speed | 330-750r/min | ||
| speed increasing ratio | I = 2.51 slow | Transfer Capacity | 0.167 kw/r.min-1 | |
| I = 2.94 fast | 0.167 kw/r.min-1 | |||
| I=3.6 Blade pump | 0.11 kw/r.min-1 (single) | |||
| I=2.5 gear pump | 0.006 kw/r.min-1 | |||
| Manipulate Way | Pull and push flexible shaft, electric control | |||
| Center distance | 403mm (blade pump output) 330mm (motor output) 210mm (gear pump output) | |||
| Length x width x height | 1175×1018×946mm | |||
| net weight | 1000kg | |||
| Bell housing | without | |||
| Application Area | It is mainly used to drive the output of gear pump, blade pump and motor in auxiliary gear box for ship. | |||
Brand: Advance Model: LJS650
| Product Description | The LJS650 type marine generator gearbox has functions of clutching and deceleration. Its transmission form is an external meshing cylindrical helical gear with three shafts and five teeth for a two-stage reduction. The gearbox consists of three main transmission components: input, transmission, and output. Hydraulic control components can achieve manual control or electro-hydraulic control, pneumatic control. | |||
| Main technical parameters | Input speed | 1800r/min | ||
| reduction gear ratio | i1=1.2;i2=1.38 | Transfer Capacity | 0.65 kw/r.min-1 | |
| Manipulate Way | Pull and push flexible shaft, electric control | |||
| Center distance | 277mm | |||
| Length x width x height | 1095×1195×1000mm | |||
| net weight | ||||
| Bell housing | without | |||
| Application Area | Mainly applied to marine auxiliary gearboxes for driving motor power output | |||
| qualification proof | ||||
Brand: Advance Model: LZ880
| Product Description | The LZ880 type marine generator gearbox features clutching and speed-up functions. Its transmission form is an external meshing cylindrical helical gear with four shafts and six teeth for three-stage speed-up. The gearbox consists of four main transmission components: input, transmission, output, and hydraulic control. The hydraulic control components can achieve manual control or electro-hydraulic control, pneumatic control. | |||
| Main technical parameters | Input speed | 170r/min | ||
| speed increasing ratio | i=8.8 | Transfer Capacity | 0.88 kw/r.min-1 | |
| Manipulate Way | Pull and push flexible shaft, electric control | |||
| Center distance | 840mm | |||
| Length x width x height | 907×1344×1702mm | |||
| net weight | 2000kg | |||
| Bell housing | without | |||
| Application Area | Mainly applied to marine auxiliary gearboxes for driving motor power output | |||
Brand: Advance Model: LZ1000
| Product Description | The LZ1000 type marine generator gearbox has functions of clutching and speed increase. Its transmission form is external meshing cylindrical helical gears with two shafts and two teeth for primary speed increase. The gearbox consists of two main transmission components: input and output. Hydraulic control components can achieve manual control or electro-hydraulic control, pneumatic control. | |||
| Main technical parameters | Input speed | 445r/min | ||
| speed increasing ratio | i=3.708 | Transfer Capacity | 0.743 kw/r.min-1 | |
| Manipulate Way | Pull and push flexible shaft, electric control | |||
| Center distance | 294mm | |||
| Length x width x height | 1150×1022×720mm | |||
| net weight | 700kg | |||
| Bell housing | without | |||
| Application Area | Mainly applied to marine auxiliary gearboxes for driving motor power output | |||
Brand: Advance Model: 2LZF1100A
| Product Description | 2LZF1100 The transfer case has speed-up and clutch functions. This gearbox has one input and two outputs, driving two vane pumps. Its transmission form is an external meshing cylindrical helical gear with four shafts and five teeth, featuring an electronically controlled shift clutch structure, which offers advantages such as quick shifting, smooth engagement, and stability. | |||
| Main technical parameters | Input speed | 1000r/min | ||
| The growth rate is equal to the corresponding transmission capacity | 2.98 | Transfer Capacity | 0.257kw/r/min | |
| Manipulate Way | Pull and push flexible shaft, electric control | |||
| Center distance | 406mm | |||
| Length x width x height | 1016×1018×946mm | |||
| net weight | 650kg | |||
| Connect the flywheel | ||||
| Bell housing | without | |||
| Application Area | Mainly used to drive the oil pump and motor output of auxiliary gearboxes for fishing boats. | |||
Brand: Advance Model: 5LZF1500
| Product Description | The 5LZF1500 type marine gearbox features single input and five outputs with clutch functionality. Its transmission form is an external meshing cylindrical helical gear ten-shaft fourteen-tooth two-stage speed reduction. This product has a reasonably designed internal structure of the gearbox, using two vane pumps to drive clutches that control the left and right vane pumps separately, enabling both simultaneous operation and step-by-step operation under various conditions. Additionally, two fast-slow shaft clutches control the generator's operation to meet different operational requirements. Through hydraulic system interlocks, the vane pumps and shaft-driven generators do not operate simultaneously, ensuring the generator can provide sufficient power support for the vessel. | |||
| Main technical parameters | Input speed | 750r/min | ||
| speed increasing ratio | 2.88 (fast gear motor) | Transfer Capacity | 0.481kw/r/min | |
| 2.26 (slow motor) | 0.373 kw/r/min | |||
| 3.3 (Blade pump) | 1.6 kw/r/min | |||
| Manipulate Way | Pull and push flexible shaft, electric control | |||
| Center distance | 462.6mm (blade pump output) 300.7mm (motor output) | |||
| Length x width x height | 1372×1378×1180mm | |||
| net weight | 1600kg | |||
| Bell housing | without | |||
| Application Area | Mainly used to drive the oil pump and motor output of auxiliary gearboxes for fishing boats. | |||
